Panel UR SP Partitioning System

The UR SP Partitioning System delivers complete visual security through solid steel sheet construction. The profiled design enhances structural integrity while maintaining a professional appearance suitable for modern industrial environments.

Complete visual privacy with solid steel construction
Profiled sheet design for enhanced structural strength
Fully demountable and relocatable system

Product information
Variants
Assembly instructions
Downloads
Combine with

Product information

Features 0.7mm profiled steel sheets welded to a robust 19x19mm frame. Available in six width options ranging from 200mm to 1200mm. Standard finish is powder-coated grey (RAL 7037) with custom RAL colors available upon request. The modular design enables full system demountability and relocation capability, providing long-term flexibility for changing security needs.

Variants

Height 2100 mm

Finish on panels, posts and powder coated accessories has the last figure variants in ART. NO.
"1" = RAL 7037 Dusty Grey; "2" RAL 1018 Zink Yellow; "5" All other RAL colours or cut/welded; "6" RAL 9005 Jet Black, "8" Hot dip galvanized

Art. Nr	Components	Width (mm)	Mesh size (mm)	Frame (mm)
36098301	Door UX SP P 980	980	Full Steel	30x20
36118901	Door UX SP P 1180	1180	Full Steel	30x20

Height 2200 mm

Art. Nr	Components	Width (mm)	Mesh size (mm)	Frame (mm)
35020511	Panel UR SP 2200x200	200	Full Steel	19x19
35030511	Panel UR SP 2200x300	300	Full Steel	19x19
35070511	Panel UR SP 2200x700	700	Full Steel	19x19
35080511	Panel UR SP 2200x800	800	Full Steel	19x19
35100511	Panel UR SP 2200x1000	1000	Full Steel	19x19
35120511	Panel UR SP 2200x1200	1200	Full Steel	19x19

Assembly Instructions

Assembly Instruction - Safe Fix System.pdf

Interactive 3D

PDF

Downloads

Name
Product sheet - PANEL UR SP_EN.pdf	Type Product sheets	Download
